A compact and efficient solution combining a nchor handling and mooring functions in one unit, ideal for saving deck space and simplifying vessel operations.
Watch Real Product Videos
The combined windlass mooring winch combines anchor handling and mooring functions in a single unit, saving deck space and simplifying vessel layout. It is available in single or double gypsy configurations, allowing simultaneous or sequential operation of anchors and mooring lines. Constructed with high-strength materials and corrosion-resistant coatings, this system provides reliable, easy-to-operate, and efficient performance suitable for vessels that require both anchoring and mooring capabilities in a compact footprint. Customizations are available for chain size, rope capacity, power source, and compliance with classification society standards.
Technical Parameters
| Item | Specification |
| Type | Single Gypsy Combined / Double Gypsy Combined |
| Chain / Rope Size | ≤32 mm standard (customizable) |
| Material | ZG270-500 steel, 316L stainless steel (optional) |
| Surface Treatment | Sandblasting, epoxy primer, polyurea topcoat; HDG optional |
| SWL | Customized per configuration |
| Motor Power | Electric / Hydraulic / Diesel-hydraulic |
| Control Method | Local / Remote (optional) |
| Lifting / Hauling Capacity | Customized |
| Application | Anchor handling and mooring on ship deck or platform |
| Certification | CCS / BV / DNV / LR / ABS / RINA / KR / NK (optional) |
Frequently Asked Questions (FAQ)?
Q: What is the delivery time for a windlass order?
A: 60 days or more, depending on the complexity and size of the windlass.
Q: Can I specify the brand of standard components?
A: Yes.
Q: Do you provide shipping services?
A: Three options are available based on customer needs: Ex-Works, FOB, or CIF.
Why Choose Wavehigh ?
Manufacturing and Anti-Corrosion Process
Our welding procedures are approved by major classification societies. The surface treatment reaches Sa2.5 blasting standard, followed by an anti-corrosion coating system consisting of zinc-rich epoxy primer, epoxy micaceous iron oxide intermediate coating, and high-build aliphatic polyurethane topcoat, with a total dry film thickness of no less than 250 μm. This coating system provides 5–10 years of corrosion protection.
For selected products, hot-dip galvanizing (HDG) is also available, improving corrosion resistance by up to 300% and offering more comprehensive protection for harsh marine environments.
Customization and Component Brands
The crane design can be customized according to customer requirements.Key components can be selected from internationally renowned brands or high-quality Chinese brands upon request. Available options include, among others, motors from ABB, Hoyel, SEW, and Siemens; hydraulic pumps from Danfoss, Parker, and Rexroth; hydraulic motors from Sai Danfoss and Staffa; and control valves from Danfoss, HAWE, and DYDEN Japan.
International brand standard components can be covered by global warranty services, while Chinese brand components are provided with a 24-month warranty. Spare parts can be delivered directly by DHL for fast maintenance support.
