Flexible and precise, perfect for complex lifting in limited spaces.
Watch Real Product Videos
Knuckle boom cranes use an articulated boom structure to provide flexible and precise lifting performance. The boom can work efficiently in limited spaces and perform multi-directional lifting with good control and stability. This crane type is suitable for complex marine and offshore operations where flexibility, compact design, and accurate load positioning are important.
Technical Parameters
| Item | Specification |
| SWL | Customized |
| Working Radius | Customized |
| Lifting Height | Customized |
| Slewing Angle | 360° / Customized |
| Luffing Angle | Customized |
| Power Source | Electric / Hydraulic / Diesel-hydraulic |
| Control Method | Local control / Remote control (optional) |
| Application | Ship deck, offshore platform, workboat, service vessel |
| Certification | CCS / BV / DNV / LR / ABS / RINA / KR / NK (optional) |
Flexible Component Configuration
We offer flexible component configurations to meet different project requirements and budget. Please specify your preferred configuration when requesting a quotation, as component selection affects the final price.
Cost-Effective Chinese Components
Qualified Chinese brands
Competitive cost
Reliable performance
Spare parts available
Suitable for cost-sensitive projects
International Brands & Global Warranty Support
ABB, Siemens, SEW, Danfoss, Parker, Rexroth and more
Internationally recognized brands
Global warranty support*
Global spare parts availability
Suitable for projects with specific brand requirements
Frequently Asked Questions (FAQ)?
Q: What is the delivery time for a crane order?
A: 75 days or more, depending on the complexity and size of the crane.
Q: What sea state levels can the crane handle?
A: Customizable according to customer needs. Sea state levels 1–6.
Q: Can I specify the brand of standard components?
A: Yes.
Q: Do you provide shipping services?
A: Three options are available based on customer needs: Ex-Works, FOB, or CIF.
Frequently Asked Questions (FAQ)?
Q: What is the delivery time for a crane order?
A: 75 days or more, depending on the complexity and size of the crane.
Q: What sea state levels can the crane handle?
A: Customizable according to customer needs. Sea state levels 1–6.
Q: Can I specify the brand of standard components?
A: Yes.
Q: Do you provide shipping services?
A: Three options are available based on customer needs: Ex-Works, FOB, or CIF.
Why Choose Wavehigh ?
Manufacturing and Anti-Corrosion Process
Our welding procedures are approved by major classification societies. The surface treatment reaches Sa2.5 blasting standard, followed by an anti-corrosion coating system consisting of zinc-rich epoxy primer, epoxy micaceous iron oxide intermediate coating, and high-build aliphatic polyurethane topcoat, with a total dry film thickness of no less than 250 μm. This coating system provides 5–10 years of corrosion protection.
For selected products, hot-dip galvanizing (HDG) is also available, improving corrosion resistance by up to 300% and offering more comprehensive protection for harsh marine environments.
Customization and Component Brands
The crane design can be customized according to customer requirements.Key components can be selected from internationally renowned brands or high-quality Chinese brands upon request. Available options include, among others, motors from ABB, Hoyel, SEW, and Siemens; hydraulic pumps from Danfoss, Parker, and Rexroth; hydraulic motors from Sai Danfoss and Staffa; and control valves from Danfoss, HAWE, and DYDEN Japan.
International brand standard components can be covered by global warranty services, while Chinese brand components are provided with a 24-month warranty. Spare parts can be delivered directly by DHL for fast maintenance support.
