Designed specifically for anchor handling, offering reliable and stable performance in lifting and lowering operations.
Watch Real Product Videos
Anchor capstans are used to handle anchor chains with precision and stability. The capstan heads are made of ZG270-500 cast steel, stainless steel (316L), or aluminum alloy, depending on application requirements. Compact and space-saving, they feature high transmission efficiency through planetary reduction mechanisms, low noise, and long-term corrosion resistance via surface treatments including sandblasting, epoxy primer, polyurea topcoat, or optional hot-dip galvanizing (HDG). Electric, hydraulic, or diesel-hydraulic power sources are available, with local or remote control options. They are suitable for ships and offshore platforms needing dependable anchor handling in limited deck space.
Technical Parameters
| Item | Specification |
| Type | Horizontal / Vertical |
| Chain Size | Customized (Standard: ≤32 mm) |
| Material | ZG270-500 steel, 316L stainless steel, aluminum alloy (optional) |
| Surface Treatment | Sandblasting, epoxy primer, polyurea topcoat; Hot-dip galvanizing (HDG) optional |
| Motor Power | Electric / Hydraulic / Diesel-hydraulic |
| Control Method | Local / Remote (optional) |
| Operation | Anchor lifting & lowering |
| Application | Ship deck, offshore platform |
| Certification | CCS / BV / DNV / LR / ABS / RINA / KR / NK (optional) |
Frequently Asked Questions (FAQ)?
Q: What is the delivery time for a capstan order?
A: 45 days or more, depending on the complexity and size of the capstan.
Q: Can I specify the brand of standard components?
A: Yes.
Q: Do you provide shipping services?
A: Three options are available based on customer needs: Ex-Works, FOB, or CIF.
Why Choose Wavehigh ?
Manufacturing and Anti-Corrosion Process
Our welding procedures are approved by major classification societies. The surface treatment reaches Sa2.5 blasting standard, followed by an anti-corrosion coating system consisting of zinc-rich epoxy primer, epoxy micaceous iron oxide intermediate coating, and high-build aliphatic polyurethane topcoat, with a total dry film thickness of no less than 250 μm. This coating system provides 5–10 years of corrosion protection.
For selected products, hot-dip galvanizing (HDG) is also available, improving corrosion resistance by up to 300% and offering more comprehensive protection for harsh marine environments.
Customization and Component Brands
The crane design can be customized according to customer requirements.Key components can be selected from internationally renowned brands or high-quality Chinese brands upon request. Available options include, among others, motors from ABB, Hoyel, SEW, and Siemens; hydraulic pumps from Danfoss, Parker, and Rexroth; hydraulic motors from Sai Danfoss and Staffa; and control valves from Danfoss, HAWE, and DYDEN Japan.
International brand standard components can be covered by global warranty services, while Chinese brand components are provided with a 24-month warranty. Spare parts can be delivered directly by DHL for fast maintenance support.
